Description:

Specifications

Engines

1 ~ 8 Cyl, N.A. or turbo charged.
RPM > 20,000

Mapping

2-dim AN / SD / MAF or 3-dimensional
3 selectable maps

Dimensions

148 mm (164 mm incl. connectors) x 181 mm x 38 mm.

Weight

700 grams

Communication

CAN 2.0b
Current loop
ASAP3 (Dyno)

Inputs

9 analogue 0-5 volt
4 NTC temperature
4 wheel speed
2 electromagnetic (turbo speed etc)
1 UEGO linear lambda sensor
8 MFIO’s
1 knock sensor

Output

6 ignition drivers
8 injector drivers
8 MFIO’s (4 PWM)

Crank and Cam

Hall effect and electromagnetic

Internal Logger

8 Mbytes, up to 64 Channels

Voltage Range

7 to 22 volts

Software

Windows 95/98/ME/2k/NT-based ECT

Enclosure

CNC machined, fully sealed

Connector

1 x 79-pin SJT MIL-spec connector

Website:

http://www.efitechnology.it/Euro6_eng.html
