SCS DeltaDash 7.0 - Racing / Motorsport Dash

MyLaps-Ben

Description:

SCS DeltaDash 7.0 supplied with plug and pigtails

This high resolution 7” full colour dash display is designed so that most vital information
is transferred over CAN by our range of ECUs.

Please read through the information below carefully to ensure easy and straightforward installation.

There are just 2 connections on the outside of the dash – a 26 way multiplug and a USB port.

You will need to supply a non-latching switch to acces the functions of the dash, and wire in the indicator switch to scroll through menus.

ROAD MODE
After initial start up the screen will enter the standard Road Mode. The design is based around a large and easy to use central rev counter, within this face is a gear position, trip counter and odometer. To the left is an anologue speedometer which can be set to
either KMH or MPH. On the right hand side are 3 user configurable anologue gauges. Additional lights appear if connected (indicators, high beam etc).

RACE MODE
A short press of the main input button will toggle into the RACE Mode. This design again centres
around a large and easy to see central rev counter with a central G sensor display. A digital speed reading allows for precise easy to seeinformation at a glance. Surrounding the central rev counter are 4 user interchangable gauges showing all important engine parameters. Additional lights appear if connected (indicators, high beam etc).



------------------------------------------------------



RPM
Always broadcast over CAN

Coolant Temperature Input
ECU Connector A Pin 11
Usually already fitted. Otherwise use
Bosch/Intermotor 55512 Temperature Sensor

Air Temp
ECU Connector A Pin 12
Usually already fitted. Otherwise use Marelli
ATS05, Webcon WAS016, Bosch/Intermotor
55715

Wheel Speed Input
Note that we recommend using a separate GPS module for ease of installation and
accuracy
ECU Connector A Pin 18
Typhoon/Tornado ECUs are hard configured to either VR or HALL. Please check your
configuration before choosing a sensor. Use ‘Sensor Setup Variables’.
On 400/800/880 use ‘Sensor Setup Variables’ to input correct figures

Oil Temperature Input
ECU Connector A Pin 31
Bosch/Intermotor 55512 Temperature Sensor.
Use ‘Oil Temp Sensor Scaling’ to match the values from this sensor.

Oil Pressure Input
ECU Connector A Pin 17
KA Sensors 1/8 NPT, 0-10 Bar

Fuel Level
Delta 400 - ECU Connector A31
Delta 800/880 - ECU Connector B29
Delta GDI - ECU Connector B32
Tornado - ECU Connector B21
Typhoon/Storm - Not Supported
Choose correct option in the relevant drop down menu. Use ‘Fuel Level Sensor Scaling’
to match the values from your fuel tanks sender unit.
