Description:

2008 Tiffin Phaeton 36QSH with 4 slides and 21203 miles. This RV is approximately 37′ 4″ in length with Cummins 360 HP engine, raised rail chassis, power mirrors with heat, power pedals, power private shades, 8 kw Onan Generator , power patio and door awnings, window awnings, slide out room toppers, gas/electric water heater, pass through storage with side swinging baggage doors, one full length pass through slide out cargo tray, aluminum wheels, water filtration system, exterior shower, fiberglass roof with ladder, 10k lb. hitch, automatic leveling system, backup and side cameras, inverter, ceramic tile floors, dual pane windows, day and night shades, convection microwave oven, central vacuum system, solid surface counter tops, washer and dryer, glass shower door with seat, two ducted AC with heat pumps.

Engine:

Engine Brand Name Cummins

Engine Type I6 Diesel Pusher

Cylinders 6

Horsepower (bhp/kW) 360 / 268.6

Horsepower RPM 2200

Torque (Ft Lbs/Nm) 1050 / 1423.6

Torque RPM 1400

Fuel Requirements Regular

Fuel Type Diesel

Turbocharged Yes

Supercharged No

Chassis Model Raised Rail Chassis

Chassis Brand Freightliner

Displacement (l) 8.3

Carburetion Type Fuel Injected

Transmission:

Transmission Type Automatic

Number Of Speeds 6

Overdrive Yes

Transmission Brand Allison

Wheels & Tires:

Wheels Composition Steel

Front Wheel Width (in) 8.25

Rear Wheel Width (in) 8.25

Number Of Axles 1

Front Tire (Full Spec) 275/80R 22.5

Rear Tire (Full Spec) 275/80R 22.5

Brakes:

Front Brake Type Hydraulic Disc

Rear Brake Type Hydraulic Drum

Anti-Lock Brakes Standard

Air Brake Standard

Exhaust Brake Standard

Technical Specifications:

Length (ft/m) 36.75 / 11.2

Width (in/mm) 101 / 2565.4

Height (in/mm) 151 / 3835.4

Wheelbase (in/mm) 228 / 5791.2

Interior Height (in/mm) 84 / 2133.6

Length (ft/ft) 36

Length (ft/in) 9

Towing Capacity (lbs/kgs) 10000 / 4536

GVWR (lbs/kgs) 32000 / 14515.2

Fuel Capacity (gal/l) 100 / 378.5

Number Of Fresh Water Holding Tanks 1

Total Fresh Water Tank Capacity (gal/l) 90 / 340.7

Number Of Gray Water Holding Tanks 1

Total Gray Water Tank Capacity (gal/l) 70 / 265

Number Of Black Water Holding Tanks 1

Total Black Water Tank Capacity (gal/l) 45 / 170.3

Propane Tank (s) Standard

Number Of Propane Tanks 1

Total Propane Tank Capacity (gal/lbs) 35.7 / 151.4

Seats:

Seat Type Bucket

Seat Material Leather

Power Adjustable Seat Yes

Reclining Seats Yes

Swivel Seats Yes

Seat Armrests Yes

Number Of Seats 2

Number Of Rows 1

Exterior:

Body Material Aluminum

Sidewall Construction Fiberglass

Number of Doors 1

Sliding Glass Door No

Number of Slideouts 4

Power Retractable Slideout Yes

Number of Awnings 1

Power Retractable Awning Yes

Screened Room No

Leveling Jack Type Front Power / Rear Power

Power Retractable Entry Steps Standard

Sky Light Standard

Roof Vents Standard

Exterior Ladder Standard

Exterior Window Shade / Cover Standard

Pass-Thru Storage Standard

Slideout Awning Standard

Instrumentation:

Voltage Meter Standard

Fresh Water Holding Tank Gauge Standard

Gray Water Holding Tank Gauge Standard

Black Water Holding Tank Gauge Standard

Trailer Level Gauge Standard

Propane Tank Gauge Standard

Identification:

Generic Type (Primary) Class A

Manufacturer Country USA

Regional Availability All Regions

Display Name Phaeton 36 QSH

Interior:

Kitchen / Living Area Flooring Type Carpet / Tile

Kitchen Table Configuration Bench Seats

Kitchen Location Center

Living Area Location Front

Number Of Oven Burners 3

Overhead Fan Yes

Layout Oven / Stove

Microwave Oven Standard

Refrigerator Size Full-Size

Refrigerator Power Mode Electric / Propane

Sink Cover / Cutting Boards Standard

Number Of Sofas 2

Sofa Material Leather

Max Sleeping Count 8

Number Of Bunk Beds 0

Number Of Double Beds 0

Number Of Full Size Beds 0

Number Of Queen Size Beds 1

Number Of King Size Beds 0

Number Of Convertible / Sofa Beds 3

Master Bedroom Flooring Type Carpet

Master Bedroom Door Style Full Sliding Door

Full Size Master Bedroom Closet Yes

Master Bedroom Mirror Doors Yes

Master Bedroom Shades / Curtains Yes

Master Bedroom Location Rear

Bed Spreads Standard

Number Of Bathrooms 1

Bathroom Flooring Type Tile

Bathroom Location Center

Toilet Type Plastic

Door Type Plastic / Glass

Bathroom Sink Standard

Bathroom Medicine Cabinet Standard

Bathroom Mirror Standard

Bathroom Vent / Fan System Standard

Sink / Faucet Standard

Power Vent Fan Standard

Electrical:

Battery Power Converter Yes

Battery Converter Amps 100

Air Conditioning Prewiring Yes

Cable Prewiring Yes

Phone Prewiring Yes

Heat Prewiring Yes

TV Antenna Prewiring Yes

Satellite Prewiring Yes

Washer / Dryer Prewiring Yes

Exterior Plugs Standard

Ground Fault Plugs Standard

Generator Standard

Other:

Smoke Detector Standard

Carbon Monoxide Detector Standard

Propane Alarm Standard

Emergency Exit (s) Standard

Towing & Hauling:

Size (in/cm) 2 / 5.1

Tongue Weight (lbs/kgs) 500 / 226.8

Rear Hitch Type Receiver

Heater & Cooler:

Air Conditioning Type Automatic

Heater Type Automatic

Water Heater Tank Capacity (g/l) 10 / 37.9

Water Heater Pump Power Mode Electrical / Propane

Water Heater Tank Bypass Yes

Freeze Proof Insulation Standard

Audio & Communication:

Number Of Radios 1

Speaker Location (s) Interior

Surround Sound Yes

Number Of Discs 1

DVD Player Standard

Number Of Televisions 2

Retractable Roof Antenna Standard

Lights:

Exterior Flood Lights Standard

Convenience:

Cruise Control Standard

Air Suspension Standard

Rear Video Backup Camera Standard

Paint & Finish:

Paint Standard

Wallpaper Yes

Interior Wood Finish Yes

Curtains / Shades Standard



All the above specification and information is for guidance purpose only and must not be relied upon. Full and exact specification must be checked and confirmed prior to purchase.
