Description:

This car was put together with no expense spared all the best components which we want to do fit

with a specially designed aero package and Flat floor

very fast and serious car but so easy to drive

not for the faint- hearted person

there is a spare package with this car at an extra cost wheels spare engine

Engine

3.6 litre

Twin Turbo

H6 engine

1030bhp

Engine Components

Custom billet 3.6 stroker crank

Mahle custom 2618 pistons

Manley H plus rods with 625 bolts

Mahle competition bearing set

AFP custom valve train Supertec Valves

AFP cams

SW Motorsport porting and polishing Motorsport heads

SMG 14mm head studs

Custom pulley kit

Cosmetic head gaskets

Dailey dry sump system

Turbos

2 x Own development air cooled bearing housing

HTA compressor wheel

76/82

K&N air filters

Zircotec rear turbo housings

Drive Train

6 speed sequential Samsonas gear box

with Cusco front Diff and Cusco rear Diff

Torqline carbon fibre propshaft

Standard front drive shafts

Drive Shaft Shop rear drive shafts

800+ brake

Brakes

Front Brakes – AP 6 pot calipers running PMU racing pads, 362mm disc

Rear Brakes – AP 4 pot racing calipers running RS29 pads, AP 320mm disc

Brake Fluid – Castrol SRF Racing

Fully braided lines

Subaru ABS system

Custom cooling system brake ducts

Electrical equipment

Syvecs S6+ including paddle shift

Map DCD

Syvecs Toucan display

Aim digital dash

Summit talon solid state digital control system

Armtech Motorsport battery isolator

Paddle Shift wireless system – Freewheel 4 channel blink stop

XAP Technology electric gear shift system

Engine main plug loom to bulkhead

Fuel System

Injectors x 6

Deatschwerks 1200 cc

Walbro lift pump

Main fuel pump – Magna Fuel 750

Fuel filters x 2 – Magna Fuel

Fully braided lines including hard pipe in internal car

Full pressure regulator and y piece – nuke performance

AFP fuel rails x 2

Fuel sample kit

Miscellaneous

Custom front mounted intercooler

Custom rear mounted radiator with 2 REVOEERC fans

Custom mounted petrol tank and swill pot setup

Custom mounted twin oil coolers

Custom mounted oil dry sump tanks specially baffled

4 x Rota Wheels MXR 18 x 11, 114 5 stud

4 x Tyres V700 Kumho 305 x 30 x 18

Sparco stearing wheel

Tillett carbon fibre seat with alloy mounts FIA approved

Sparco 6 point harness

Custom electrics

Custom oil breather tank

Electric power steering cooling radiator

Carbon mirrors

Radiator side intakes

Custom carbon fibre rear fire wall

Custom carbon fibre rear floor

RJ window catches

Carbon fibre rear wing supports

Fire extinguisher OMP

Custom jacking points

Suspension

Nitron 3 way adjustable shocks

White Line 24mm front anti roll bar

White Line 19mm rear anti roll bar

White Line fully poly bushed

White Line drop links front and back

Bodywork

Fully fibre glassed doors, wings, bonnet and boot lid

All lightened

Perspex windows

Wide Arch kit

Light weight front covers

Carbon rear lights

Front bumper fibre glass

Lower front bumper carbon fibre including cannards

Underneath front aero flat floor including rear blown diffuser

Twin element rear spoiler – made by D J Racecars
